Fire-resistant Halogen free Shipboard Power Cable 0.61KV

Fire-resistant Halogen free Shipboard Power Cable 0.61KV

Ang cable ay inilaan para sa power, lighting at control system ng shipboard at off-shore building, at magagamit din ito sa metalurgical industry chemical works, power planted at mina atbp.

Marine Electrical Cable SPECIFICATION & STANDARDS

IEC 60288 IEC60092-350 IEC60092-353 IEC60092-359

IEC60092 351 IEC60332-1 IEC60332-3Cat.A

IEC61034-2 IEC 60754-23A

Konstruksyon:

Konduktor: lata na tanso

pagkakabukod:EPR/XLPE

tagapuno

Tape

Inner sheath: PCP/CSP/PVC/PO (SHF1, SHF2)

Nakabaluti:tinned copper wire tirintas

(Galvanized steel wire tirintas)

Panlabas na kaluban:PVC/PCP/PO (SHF1, SHF2)

Mga Tampok ng Flammability:

DA:Single cable flame retardant

SA:Bunched cable flame retardant

SC:Bunched cable flame retardant,halogen-free, low-smoke, low-toxicity.

Mga pagtutukoy:

Mga core:1, 2, 3, 4, 5

Mga Nominal na Cross-section na Lugar:1 mm², 1.5mm²,2.5mm²,4mm²,6mm²,10mm²,16mm²,25mm²,

35mm²,50mm²,70mm², 95mm²,120mm²,150mm²,185mm²,240mm²,300mm².

Mga Sertipiko:

CCS,LR,ABS,DNV,BV,GL,NK,RINA;90℃

Bibigyan ka namin ng pinakamahusay na kalidad, mapagkumpitensyang presyo at kasiya-siyang serbisyo.
