Marine TeleCommunication Cable

ESPISIPIKASYON AT MGA PAMANTAYAN

IEC 60288 IEC60092-351 IEC60092-375 IEC60092-359

IEC60332-1 IEC60332-3Cat.A IEC 60331

Konstruksyon:

1. Konduktor: lata na tanso

2. Pagkakabukod:XLPE/EPR

3. Tape

4. Indibidwal na screen:tinned copper wire na tinirintas

5. Tape

6. Inner sheath:PO(SHF1, SHF2)

7. Screen/Armored:tinned copper wire tirintas

8. Panlabas na kaluban:PO(SHF1, SHF2)

Mga Tampok ng Flammability:

DA:Single cable flame retardant

SA:Bunched cable flame retardant

SC:Bunched cable flame retardant, halogen-free, mababang usok, low-toxicity.

Mga pagtutukoy:

Mga core:1, 2, 3, 4, 5, 7, 10, 12, 14, 16,19, 24, 27, 30, 33, 37.

Mga Nominal na Cross-section na Lugar:0.75 mm²,1 mm², 1.5mm²,2.5mm²,4mm²,6mm²,10mm²,16mm²,25mm²,

35mm²,50mm²,70mm², 95mm²,120mm²,150mm²,185mm²,240mm²,300mm².

Application ng Marine Cable:

Ang cable ay inilaan para sa komunikasyon, computer at information proceeding unit ng shipboard at naval ship, at magagamit din ito sa metalurgical industry chemical works, power planted at mina atbp.

Mga Sertipiko:

CCS,LR,ABS,DNV,BV,GL,NK,RINA;85℃
